Molybdenum Foil

Production Process

1. Raw Material Refining: Adopts high-purity molybdenum powder (particle size 3-5μm) via hydrogen reduction, ensuring low oxygen content (≤10ppm) to avoid brittle fracture. 2. Precision Rolling: Combines cold rolling with intermediate vacuum annealing (1200-1400℃, holding time 2-3h) based on recrystallization theory, controlling grain size at 5-20μm to improve ductility. 3. Finishing Treatment: Surface polishing (Ra ≤0.2μm) and vacuum degassing (10⁻⁴Pa) to eliminate surface defects and internal stress, ensuring dimensional stability. Product Characteristics (Data Supported) • Dimensional Precision: Thickness range 0.01-0.1mm, tolerance ±0.001mm (laser thickness gauge monitoring); width up to 300mm, length customizable. • Mechanical Performance: Tensile strength ≥550MPa, elongation ≥8% (tested by universal testing machine), maintaining stability at 1000℃ (strength retention rate ≥80%). • Thermal/Electrical Properties: Thermal conductivity 138W/(m·K) (25℃), electrical resistivity 5.2×10⁻⁷Ω·m, suitable for high-temperature current-carrying components.

Quality Control & Certification

Equipped with a full set of detection equipment: X-ray diffraction (grain structure analysis), ultrasonic flaw detection (internal defect inspection), and RoHS/REACH compliance testing to meet EU and North American environmental standards. Each batch provides a quality inspection report (COA).

Sales & After-Sales Service

• Supply Capacity: Monthly output 5 tons, supporting small-batch customization (minimum order 1kg) and bulk orders, with a delivery cycle of 7-15 working days (global logistics via DHL/FedEx).

• Technical Support: 24-hour professional team provides application guidance (e.g., welding parameters, heat treatment suggestions) and technical solutions.

• Warranty Service: 1-year quality warranty; if quality problems occur due to product itself, free replacement or refund is provided, with efficient cross-border after-sales response (response time ≤4 hours).

Our molybdenum foil integrates advanced craftsmanship and strict quality control, providing reliable material solutions for global high-tech enterprises.

Shaanxi Changlong Jiuzhou Metal Technology Co., Ltd. is a professional company engaged in the production, research and development, and sales of non-ferrous metals such as titanium and titanium alloys, zirconium and zirconium alloys
A high-tech enterprise specializing in its alloy strip and foil products. The company was established in 2003 and is located in the High-tech Development Zone of Baoji City, Shaanxi Province, known as the "Titanium Valley of China", covering an area of over 50 mu.
Changlong Strip and Sheet has a complete set of standard production lines for titanium and titanium alloys, zirconium and zirconium alloy strips and foils, which are well-equipped, highly automated and have high production efficiency. The foil product specifications are T0.03~0.15mm*W850mm*L, and the strip size is T0.15~6mm*W1250mm* L. We supply regular titanium and zirconium in stock for a long time, and can also customize the production of special specifications and special materials of metal strips, foils, plates, sheets, etc. The application scope of the products covers many fields such as nuclear power, seawater desalination, metallurgy, petrochemicals, environmental protection, electronics, mechanical manufacturing, medical equipment, ships, aerospace, outdoor products, etc. The company produces and sells titanium and titanium alloys, zirconium and zirconium alloys and other related products that comply with national and American standards. These products not only meet the demands of various domestic industries for high-end strip and foil materials, but also are exported overseas to many countries such as the United States, Germany, Switzerland and Finland. Our production process and products have all passed the GB/T19001-2016 /ISO9001:2015 Quality Management System Certification, GB/T 45001/ISO 9001 Environmental Management System certification, and GB/T 45001/ISO
45001 Occupational Health and Safety Management System Certification. In recent years, Changlong Plate and Strip has been focusing on improving the production of titanium strips and titanium foils, while also strengthening the research and exploration of zirconium strip and foil production and special titanium-zirconium plate and strip materials such as ultra-wide and ultra-thin ones. It has successfully developed and produced heavy-duty large rolls of zirconium strips, ultra-thin wide titanium strips, titanium alloy strip and foil materials and other products. Among them, many production technology invention patents have been authorized by the National Patent Office.
With the company's strength and product quality being recognized by a wide range of users, Changlong Strip has begun to draw a new development blueprint. In 2022, land acquisition was initiated to build the Plate and Strip Science and Technology Park. This is a production line for non-ferrous metal plate and strip materials that integrates production, research and development, warehousing, exhibition, and office functions. It aims to reduce material costs, expand the width and breadth of the product line, and further enhance product quality and performance through technology and equipment. Through the improvement of technical equipment and management, a processing giant vessel for non-ferrous metal sheet, strip and foil materials with an annual production capacity of over ten thousand tons, mainly focusing on titanium and zirconium sheet, strip and foil materials, will be created. With the perseverance of dedicated dedication and the driving force of enterprise development empowered by technology, Changlong Sheet and Strip is bound to achieve a leapfrog development in the processing of titanium, zirconium and other non-ferrous metal sheet, strip and foil materials.
Shaanxi Changlong Jiuzhou Metal Co., Ltd. adheres to the concept of "innovation-driven, win-win development, integrity first, and customer supremacy", and is constantly striving to provide you with high-quality products, technologies and services, and to become your loyal partner for long-term development.

Our company has three cold rolling production lines, namely 650, 950 and 1450 type 20-roll cold rolling production lines, and is equipped with related auxiliary equipment such as slitting, uncoiling, tension leveling and surface treatment. We have strong processing capacity and excellent production quality, and have comprehensively met the customers' demands in terms of quality, price and efficiency.
